| Company | Country | Ghana | Year | 2026 | |
Equipments Info: | |||||
| Chicken type: | Broiler on ground | Dimension | 16x120x2.4m | Capacity/birds: | 28800 |
| Feed line | 4 | Water line | 5 | ||
| Including: | 1. Feed line 2. Drinking system 3. Fan system | ||||
House Info: | |||||
| Size | 120mx16mxH2.4mX20 | Paint | Galvanized | Roofing | 0.4m corrugated sheet, V840 +150mm fiber glass wool (16KG/m³) insulation |
| Structure | C-Steel | Brick wall | Open Side System | Purlin | C purlin |
| Ceiling | 30mm PU sandwich panel | Wall | Brick wall | Doors | Insulation door |
| Project Pictures | |||||
House Info: | |||||
| Size | 110m*18m*4.2m | Wind speed | 250km/h | Roofing | 0.5mm corrugated sheet |
| Structure | H&I steel | Paint | Alykd paint | Purline | C purline |
| Ceiling | 0.4mm corrugated sheet+50mm fiber glass wool insulation | Wall | 50mm PU sandwich panel | Brick wall | 0.5m |
| Columns | Exposed | Roof drainage | natural drainage | Doors | Insulation door with Zn-Al-Mg panel |
| Project Pictures | |||||
| |||||
